Steam Butterfly Valve

Product Description

Angle seat valves, which are also referred to as Y-type globe valves, pneumatic control angle seat valves, and pneumatic angle seat valves, are commonly used in steam applications. These valves are highly efficient, compact, and feature a guided design that maintains a consistent flow rate. Angle seat valves are operated by a single-acting pneumatic actuator that includes spring safety protection. When selecting an angle seat valve, it is important to choose between normally open or normally closed options. By doing so, you can ensure that the valve operates effectively and efficiently in your specific application.

Steam pressure reducing valve installation

The diaphragm can be installed in different ways depending on the placement of the pipe. It can be positioned either above or below the pipe, or even on a vertical pipe. Prior to installation, it is important to ensure that the end of the pipe is properly reamed and the thread length is cut to an appropriate size. Additionally, it is crucial to blow out the pipeline to eliminate any loose oxide layers or foreign substances that may pose a risk to the valve seat. By following these installation procedures, the diaphragm can be effectively secured and the pipeline can function smoothly.

Ensure that the regulating valve is correctly installed on the pipeline by orienting the arrow on the valve body in the same direction as the fluid flow. By doing so, you can effectively regulate the flow of fluid within the pipeline.

Ensure that the DN6 or DN10 balance pipe is connected from the diaphragm chamber to a location that is at least 18 inches away from the pressure relief pipe. However, it is advisable to place the balance pipe even farther away from the regulating valve for better performance.

Consider installing a valve as a safeguard to stabilize the fluctuation of the regulator valve in case the pressure becomes unstable. The best option could be a needle valve installed on the control line. By throttling the valve, the unstable pressure will be stabilized and the fluctuation controlled.

Technical Data

Application

Packaging & Shipping

Each plywood case will be used to pack one pump set and includes fixed timbers and plastic film for added protection during shipping. We ensure that all our packaging adheres to strict quality standards to ensure the safe delivery of our products.

，。，。
，。
